Mission Type Magnum XP Parts List

Item #DescriptionQty.Base Part NumberProcessing Number Item #DescriptionQty.Base Part NumberProcessing Number
1Casing, 14X12X22124022-01-30A651120206 25Bearing, Outboard (14X12 )120616-2658413307
 Casing, 12x10x23 25008-01-30A662001001  Bearing, Outboard (12X10 & 8X6)2 20616-3661009001
 Casing, 8x6x18 25289-02-30A662002089 26Seal, Bearing Cover17496-267658408802
2Nut, Casing323932-61648402014 27Lock Washer16124-6658407002
3Stud, Casing (14X12 & 12X10)323862-86658403308 28Lock Nut, Bearing16123-6658406509
 Stud, Casing (8X6)163862-90601208285 29Oil Seal, Bearing Cover220619-04658413638
 Stud, Casing (8X6)163862-92648401118 30Drive Screws612530601482417
4Gasket, Casing (14x12x22)210399-55-01658410501 31Nameplate123017601501505
 Gasket, Casing (12x10x23) 25012-01-01661010001 32Shaft124028-33656420007
 Gasket, Casing (8x6x18) 25012-02-05662010032 33Key, Coupling14372-30-21658405055
5Cover, Front (14x12x22)124021-01-30654310309 34Cover, Bearing O.B.124033-01-01654314004
 Cover, Front (12x10x23) 25009-01-30662014003 35Bolts, Bearing Cover23861-139648401081
 Cover, Front (8x6x18) 25291-02-30662014129 36Washer, Bearing Cover23936-19-L8648402030
6Impeller, 14×12 Clockwise Rot. 22”124024-X0-HS662005003 37Nuts, Bearing Housing23932-62658404702
 Impeller, 12×10 Clockwise Rot. 23” 25010-Y0-30662005002 38Bolt, Bearing Housing43861-138648401057
 Impeller, 8×6 Clockwise Rot. 18” 25292-T0-30662005018 39Washer, Flat23936-19-L8648402030
7Seal, Impeller Nose17496-158658408109 40Bolt, Packing Gland23861-165601408289
8Key, Impeller14372-29-21658405006 41Gland, Packing Half224034-01-13654315100
9Nose, Impeller ( Hex Design)124025-04-25L652309601 42Packing Set18264-344-K658409503
 Nose, Impeller (Two Flat Design) 24025-01-25L652309600 43Screw, Cap23909-04-87658404207
 Nose, Impeller (2 Flat Ion Nitride) 24025-03-25L662014054 44Plug, Grease18505-1601474695
10Screw, Set114430-19658411400 45Breather18267-1601473689
11Jam Nut124026-25L658414255 46Plug, Fitting119368661010020
12Seal, Impeller17496-153658408059 58Plug, Pipe28505-02-01658409859
13Mechanical Seal (Crane Type)124036658416102 59Plug, Pipe18505-06-01658410006
14Stuffing Box, Mech. Seal (14X12)124027-01-30653322305 60Tag, Mechanical Seal122566603445727
 Stuffing Box, Mech. Seal (12X10) 24027-02-30662014002 Packed Split-Box and Wearplate
 Stuffing Box, Mech. Seal (8X6) 25290-02-30662014128 47Wearplate, Split Box124023-01-XX654310507
15Bolt, Stuffing Box23861-117648401016 48Packing Set18264-345-K658409552
16Sleeve, Shaft124029-21BZ656422201 49Nut and Washer Assembly222216-02658413935
17Seal, Sleeve17496-234658408505 50Bolt, Split-Box23861-1681/2-13×4 lg Gr 5
18Slinger124030-01-13654311604 51Stuffing Box, Split224037-01-87654317007
19Seal, Slinger17496-238P658408554 52Latern Ring Half224039-13658418207
21Oil Seal, Inboard Bearing220619-03658413604 53Fitting, Grease119368-01601499403
21Bearing, Inboard120615-2658413000 54Screw, Cap23909-13-87658404405
22Frame 14X12124031-01-01654312008 Auxiliary Tools
 Frame 12X10 24031-02-01662014001 55Tool, Impeller Nose & Nut124040658420203
 Frame 8X6 25293-02-01662014130  Tool, Impeller Nose (HEX) Standard Hex Socket
23Housing, Bearing124032-01-01654313006 56Tool, Impeller Removal124041658420252
24Seal, Bearing Housing17496-272658408901 57Tool, Shaft Holder124042658420302
